Side entry type, top entry type;
Single bag type, multi bag type;
Filtration precision 1um to 200um;
Flow rate: 20 to 480 m³/h;
Bag Nos: 1 to 15 pcs
OEM and ODM available.
 |
SS304 316L Single Bag Water Pre Filter Housing With 10 20 40 Inch Length
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | QRZ |
| Model Number: | QSF-DF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | $150.00 - $6,000.00/sets |
| Packaging Details: | Regular packaging |
| Delivery Time: | 5-8 weeks |
| Supply Ability: | 100 units/day |
|
Detail Information |
|||
| Product Name: | Bag Prefilter | Application: | Water Pre Treatment |
|---|---|---|---|
| Housing Material: | SS304, 316L | Housing Length: | 10 /20 / 40 Inch |
| Permeable Size: | 1um To 200um | Permeable Rate:: | 20 ~ 480 Tph |
| Filter Bag Material: | Ss | Filter Bag Nos: | 1 ~ 15 |
| Working Temperature: | 100℃ | Working Pressure: | 0.6MPa, 1.0MPa |
| Port: | Qingdao, Shanghai, Tianjin | ||
| High Light: | Single Bag water pre filter housing,SS304 water pre filter housing,316L water pre filter housing |
||
Product Description
Single Bag Water Prefilter Housing with 10/20/40 Inch Length and SS304/SS316 Material
Product Description
Stainless Steel Pressure Bag Prefilter
Pressure bag filter is pre-filtration device to remove SS in raw water. Driven by a certain pressure, water flow through filter bags and large particle suspended solids are trapped. Chinwater design and manufacture all types of stainless steel bag filters, including
Single bag type, multi bag type;
Filtration precision 1um to 200um;
Flow rate: 20 to 480 m³/h;
Bag Nos: 1 to 15 pcs
Single bag type, multi bag type;
Filtration precision 1um to 200um;
Flow rate: 20 to 480 m³/h;
Bag Nos: 1 to 15 pcs
Single and Multi Bag Filters
Key Performance
|
SN
|
ITEM
|
SPECIFICATION
|
|
1
|
Model
|
QRZ-DF
|
|
2
|
Capacity
|
20 ~ 480 m³/h
|
|
3
|
Housing Material
|
SS 304, 316L
|
|
4
|
Housing Length
|
10 / 2o /40 inch
|
|
5
|
Filter Bag Material
|
melt blown fabric,
|
|
6
|
Filter Bag Nos
|
1 to 15 pcs
|
|
7
|
Bag Pore Size
|
1 to 2ooum
|
|
8
|
Working Pressure
|
0.6 Mpa, 1.0Mpa (or as required)
|
|
9
|
Working Temperature
|
Maximum 100℃
|
|
10
|
Feed Type
|
Side entry / top entry
|
|
11
|
Control Mode
|
Automatic / manual
|
Model and Specification
|
MODEL
|
Housing Size
(Φ x H) (mm)
|
CAPACITY (m³/h)
|
Inlet OD
|
Bag Size
(Φ x H) (mm)
|
Bag Nos
|
|
QRZ-DF1-1F
|
Φ219*410
|
20
|
DN50
|
Φ180*405
|
1
|
|
QSF-DF1-2F
|
Φ219*810
|
40
|
DN65
|
Φ180*810
|
1
|
|
QRZ-DF2-2F
|
Φ400*810
|
50~80
|
DN80
|
Φ180*810
|
2
|
|
QRZ-DF2-3F
|
Φ500*810
|
120
|
DN100
|
Φ180*810
|
3
|
|
QRZ-DF2-4F1
|
Φ550*810
|
140
|
DN100
|
Φ180*810
|
4
|
|
QRZ-DF2-4F2
|
Φ600*810
|
150
|
DN125
|
Φ180*810
|
4
|
|
QRZ-DF2-5F
|
Φ650*810
|
160
|
DN125
|
Φ180*810
|
5
|
|
QRZ-DF2-6F
|
Φ750*810
|
200
|
DN150
|
Φ180*810
|
6
|
|
QRZ-DF2-8F
|
Φ800*810
|
220
|
DN150
|
Φ180*810
|
8
|
|
QRZ-DF2-9F
|
Φ850*810
|
240
|
DN200
|
Φ180*810
|
9
|
Main Application
* Pretreatment in Waste water and sewage treatment plant
* Pre-treatment in Water purification and desalination
* Food & Beverage Industry
* Petro chemical
* Oil & Gas engineering
* Painting & Coating
* Textile printing, dying, pulping
* Food oil production
* Petro chemical
* Oil & Gas engineering
* Painting & Coating
* Textile printing, dying, pulping
* Food oil production
* Pharmaceutical
* Electronics and Electroplate
* Metal machinng
Packing & Delivery
Package
Typically, carbon steel quartz sand filter doesn't require package. We provide wood box or paper box as required.
Quartz sand could be filled in tank before shipment.
Shipment
Capacity less than 25 m³/h, container loading.
Over 25 m³/h, we suggest bulk cargo.
