PVDF Curtain Membrane For Submerged MBR Hollow Fiber Ultrafiltration 40KG
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | QRZ |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | $9.00 - $23.00/sets |
| Packaging Details: | Regular packaging |
| Delivery Time: | 5-8 weeks |
| Supply Ability: | 100 units/day |
|
Detail Information |
|||
| Condition: | New | Weight (KG): | 40 |
|---|---|---|---|
| Video Outgoing-inspection: | Not Available | Machinery Test Report: | Provided |
| Marketing Type: | Ordinary Product | Warranty Of Core Components: | 1 Year |
| Core Components: | Pressure Vessel | Warranty: | 1 Year |
| Applicable Industries: | Food & Beverage Factory, Other | Showroom Location: | None |
| Product Name: | Submersible MBR Unit | Application: | Solid-Liquid Separation In Water Treatment |
| Material: | PDVF | Type: | Hollow Fiber Membrane |
| Operating Pressure: | -0.02-0.05Mpa | Operating Temperature: | 15-40℃ |
| Port: | Qingdao, Shanghai, Tianjin | ||
| High Light: | PVDF Curtain hollow fiber membrane,Submerged MBR hollow fiber membrane,PVDF Curtain Membrane 40KG |
||
Product Description
PVDF Curtain Membrane for Submerged MBR Hollow Fiber Ultrafiltration Weight KG 40
Product Description
Specification
|
Basic parameters of hollow fiber curtain membrane modules
|
|
|
|
|
||||
|
membrane modules model
|
QRZ-10
|
QRZ-15
|
QRZ-18
|
QRZ-20
|
||||
|
effective membrane area
|
10㎡
|
15㎡
|
18㎡
|
20㎡
|
||||
|
dimensions
|
1010*535*45 mm
|
1515*535*45 mm
|
1515*535*45 mm
|
2020*535*45 mm
|
||||
|
membrane wire diameter (inner/outer)
|
1.1/2.2 mm
|
1.1/2.2 mm
|
1.1/2.2 mm
|
1.1/2.2 mm
|
||||
|
filtration aperture
|
0.05um
|
0.05um
|
0.05um
|
0.05um
|
||||
|
porosity
|
50-70%
|
50-70%
|
50-70%
|
50-70%
|
||||
|
recommended
aeration rate
|
5m³/h*piece
|
5m³/h*piece
|
5m³/h*piece
|
5m³/h*piece
|
||||
|
longitudinal strength
|
≥200N
|
≥200N
|
≥200N
|
≥200N
|
||||
|
filtering mode
|
submerged sucking filtration
|
|
|
|
||||
|
membrane modules model
|
QRZ-15
|
QRZ-20
|
QRZ-35
|
QRZ-40
|
|||
|
membrane modules model
|
15㎡
|
20㎡
|
35㎡
|
40㎡
|
|||
|
dimensions
|
1250*1000*30mm
|
1250*1500*30mm
|
1250*2000*30mm
|
1250*2000*30mm
|
|||
|
membrane wire diameter (inner/outer)
|
1.1/2.2 mm
|
1.1/2.2 mm
|
1.1/2.2 mm
|
1.1/2.2 mm
|
|||
|
filtration aperture
|
0.05um
|
0.05um
|
0.05um
|
0.05um
|
|||
|
porosity
|
50-70%
|
50-70%
|
50-70%
|
50-70%
|
|||
|
recommended
aeration rate
|
60-120m³/㎡*h(㎡=Projected area of membrane components)
|
|
|
|
|||
|
longitudinal strength
|
≥200N
|
≥200N
|
≥200N
|
≥200N
|
|||
|
filtering mode
|
submerged sucking filtration
|
|
|
|
|||
Packing & Delivery
Wooden box packaging
